Description
The SECO 03275915 is a solid carbide turning insert in the CCMT series, designed for precision metal cutting on CNC lathes and turning centers. It carries the industry standard designation CCMT21.51-M3 and ISO code CCMT060204-M3. The insert features a CVD-applied Duratomic multilayer coating TiCN, Al2O3, and Cr engineered for wear resistance and thermal stability at the cutting edge. With an 80-degree diamond shape, a 1/4-inch inscribed circle, and a 1/64-inch corner radius, this insert is built for general-purpose turning, facing, and boring operations where surface finish and tool life are the primary concerns.
This insert is primarily suited for machining stainless steel (ISO material group M) and is also applicable to general steel (ISO group P). It fits CCMT-style toolholders using screw-type clamping and is appropriate for production turning environments where consistent chip control is required. The M3 chip breaker geometry provides positive rake cutting action with a chamfered and honed edge, making it effective across a range of depths of cut up to 0.2378 inches. Machinists working in job shops and production facilities will find it well-suited for both roughing passes and semi-finish turning on stainless components.
Key Features
- CVD Duratomic multilayer coating (TiCN, Al2O3, Cr) for extended tool life on stainless and steel
- 80-degree diamond insert shape with 1/64-inch corner radius for versatile turning geometry
- M3 chip breaker with positive rake (18 degrees) and chamfered and honed cutting edge
- Screw-held CCMT mounting style for secure seating in standard CCMT toolholders
- 2 cutting edges per insert for cost-effective indexing
- Multi-use application: boring, facing, and turning from a single insert geometry
Compatibility
Designed for use in CCMT-style screw-clamp toolholders. Meets ANSI and ISO standards for CCMT insert geometry. Compatible with material grades M25, M30, and M35 per ISO classification. Industry standard number CCMT21.51-M3; ISO code CCMT060204-M3.
Installation Notes
Installation is performed by a machinist or CNC toolroom technician. Power down and lock out the machine spindle before indexing or replacing the insert. Seat the insert fully against the toolholder pocket before tightening the clamping screw, and verify there is no rocking or gap at the seating surfaces. Follow the toolholder manufacturer’s recommended clamping torque procedure to avoid insert fracture or pocket damage.
Technical Specifications
- Industry Standard Number: CCMT21.51-M3
- ISO Code: CCMT060204-M3
- Insert Shape: Diamond 80 (80-degree included angle)
- Insert Material: Solid Carbide
- Manufacturer Grade: TM2501
- Coating: TiCN, Al2O3, Cr CVD Duratomic
- Inscribed Circle: 1/4 inch (0.2500 inches)
- Corner Radius: 1/64 inch (0.0157 inches)
- Insert Thickness: 3/32 inch (0.0937 inches)
- Insert Length: 0.2539 inches
- Hole Diameter: 0.1142 inches
- Maximum Depth of Cut: 0.2378 inches
- Rake Angle: 18 degrees (Positive)
- Relief Angle: 7 degrees
- Chip Breaker: M3
- Cutting Edge Style: Chamfered and Honed
- Insert Hand: Neutral
- Number of Cutting Edges: 2
- Insert Holding Method: Screw
- Primary Workpiece Material: Stainless Steel (ISO Group M)
- Secondary Workpiece Material: Steel (ISO Group P)
- Material Grade: M25, M30, M35
- Standards: ANSI, ISO
- Series: CCMT-M3
- Weight: 0.2 pounds
- Package Quantity: 1
- Minimum Order Quantity: 10
Standard Information
- Brand: SECO
- Manufacturer Part Number: 03275915
