Description
U.S. Seal Pump Shaft Assembly | PS-514
1-5/8″ Shaft Mechanical Seal with Buna Components
Product Overview
As a retailer of quality pump components, I’m offering this professional-grade U.S. Seal mechanical seal assembly, specifically engineered for 1-5/8″ shaft applications. This Buna-equipped seal provides reliable sealing performance for various pump applications.
Technical Specifications
| Specification | Detail |
|---|---|
| Model Number | PS-514 |
| Manufacturer | U.S. Seal |
| Shaft Size | 1-5/8″ |
| Elastomer | Buna |
| Type | Mechanical Seal |
| Design | Spring-loaded |
| Face Material | Ceramic/Carbon |
| Spring | Stainless Steel |
Engineering Features
- High-precision seal faces
- Dynamic spring loading
- Buna elastomer seals
- Self-aligning design
- Balanced seal profile
- Anti-rotation features
- Precision-lapped faces
Performance Characteristics
- Operating Temperature: Up to 220°F
- Maximum Pressure: 150 PSI
- Media: Water and compatible fluids
- Speed Rating: 3600 RPM max
- Rotation: Bi-directional
- Service Life: Extended duty
Design Benefits
- Reliable sealing performance
- Minimized maintenance needs
- Enhanced durability
- Low friction operation
- Consistent seal face contact
- Reduced wear rates
- Optimal pressure distribution
Applications
- General purpose pumps
- End suction pumps
- Split case systems
- Vertical mount pumps
- Water circulation
- Process applications
Installation Features
- Factory assembled unit
- Drop-in replacement design
- Standard dimensions
- Simple installation process
- Alignment indicators
- Complete assembly package
Material Properties
- Buna elastomer construction
- Ceramic sealing face
- Carbon mating ring
- Stainless steel components
- Chemical-resistant design
Product Identification
SKU: PS-514 Categories: Pump Parts
This U.S. Seal mechanical seal assembly is manufactured to exact specifications, ensuring reliable sealing and extended service life in demanding pump applications
