Description
The PANDUIT F91ER3NB1SNM007 is a single-fiber OS2 simplex fiber optic cable assembly designed for low-loss, long-distance data transmission in structured cabling installations. Built with a 1.6mm cable diameter and terminated with SC connectors on each end, this assembly uses a physical contact (PC) polish to minimize back reflection and insertion loss. The OFNR (Optical Fiber Nonconductive Riser) rating qualifies it for vertical runs between floors in commercial and industrial buildings. Network technicians and low-voltage cabling contractors are the primary installers of this assembly.
This cable assembly is suited for single-mode OS2 fiber networks in commercial office buildings, data centers, campus backbone runs, and riser pathways. The simplex configuration carries a single fiber channel, making it appropriate for unidirectional links or applications where separate transmit and receive cables are run independently. The SC connector format remains widely deployed in telecom closets, patch panels, and active equipment across enterprise and carrier environments.
Key Features
- OS2 single-mode fiber core for long-distance, low-attenuation transmission
- 1.6mm cable diameter for flexible routing in tight conduit and cable management systems
- SC connectors with PC polish for reliable physical contact and low back reflection
- OFNR-rated jacket approved for riser installations per NEC Article 770
- Simplex construction for clean, single-channel fiber routing
Compatibility
Designed as an OEM-style replacement or new-installation cable assembly for OS2 single-mode SC simplex fiber optic networks and patch panel systems.
Installation Notes
Installation should be performed by a qualified low-voltage cabling technician familiar with fiber optic handling practices. Avoid bending the cable below its minimum bend radius and keep connector end-faces capped or clean until termination. Power down active fiber equipment before connecting or disconnecting the assembly. Riser installations must comply with NEC Article 770 requirements for the appropriate building fire zone.
Technical Specifications
- Fiber Type: OS2 Single-Mode
- Fiber Count: 1 (Single-Fiber)
- Cable Diameter: 1.6mm
- Connector Type: SC
- Polish Type: PC (Physical Contact)
- Cable Configuration: Simplex
- Jacket Rating: OFNR (Optical Fiber Nonconductive Riser)
- Unit of Measure: EA
- Quantity Per Unit: 1
Standard Information
- Brand: PANDUIT
- Manufacturer Part Number: F91ER3NB1SNM007
