Description
CF1P-020D Glycerine-filled Gauge
Our CF Series of glycerine-filled gauges offer an accurate, inexpensive option for your pressure gauge needs. CF gauges are constructed with a stainless steel case, bronze bourdon tube, and connection, and a polycarbonate lens. All of our gauges come with a built-in snubber. Standard gauge faces are designed with both PSI and BAR scales in a variety of ranges from vacuum to 10,000 psi (6,000 psi for 1.5″ gauges). Certificates of Accuracy are available for an additional cost.
Features:
- 304 Stainless Steel Case & Bezel
- Phosphor Bronze Bourdon Tube
- Bronze Connection
- Polycarbonate Lens
- Built-in Snubber
- Range: Vacuum to 10,000 psi
- Dual Scale: psi & bar
- Accuracy: ± 1.6% FSD
- Temperature Range: -13º to 180ºF
- Certificate of Accuracy Available (see page 14 for details)
If it’s SAE Swivel mount, it also includes:
- 304 Stainless Steel Case & Bezel
- Phosphor Bronze Bourdon Tube
- SAE 7/16-20 Bronze Connection
- Polycarbonate Lens
- Built-in Snubber
- Range: Vacuum to 10,000 psi
- Dual Scale: psi & bar
- Accuracy: ± 1.6% FSD
- Temperature Range: -13º to 180ºF
