Description
Discover the CDS-1P-002E Compound Dry Gauge, a reliable and accurate pressure gauge designed for a variety of applications. This gauge features a steel case, phosphor bronze bourdon tube, bronze connection, and polycarbonate lens, ensuring durability and precision in pressure measurement.
Main Features:
- Steel Case
- Phosphor Bronze Bourdon Tube
- Bronze Connection
- Polycarbonate Lens
- Built-in Snubber
- Range: Vacuum to 6,000 psi
- Dual Scale: psi & bar
- Accuracy: ± 1.6% FSD
- Temperature Range: -40º to 180º F
- Certificate of Accuracy Available (see page 14 for details)
The CDS-1P-002E is part of the CDS series known for its accuracy and affordability in pressure gauge solutions. Whether it’s stem mount or center back mount, the CDS gauges offer consistent performance and reliability. Upgrade your pressure measurement equipment with the CDS-1P-002E Compound Dry Gauge.
Manufacturer: Dynamic Fluid Components
Series: CDS
Pressure Range: 0-30 psi
Gauge Dial Size: 2.5 inches
Measuring System: psi, bar
Temperature Rating: -40º to 180º F
