Description
The 24V-DC power supply is specially designed to power the Plug-in-Pool system. In order to ensure a safe installation, power supplies are made up of two compartments which make it possible to connect the primary and the secondary independently.
All power supplies are equipped with an ON / OFF switch to facilitate turning on the lights, a resettable circuit breaker to protect the transformer and lights in case of overload and quick connectors to facilitate electrical connections.
Two sockets maximum on this 92W version.
Technical Features:
-
Disconnect the power supply before opening the service cover
-
Specific power supply for Plug-in-Pool System
-
Power supply voltage (input) 120 VAC, 60 Hz
-
Output voltages 21V DC
-
Maximum power consumption 92W
-
Overall Dimensions 310 x 150 x 100mm (12,2 x 5,9 x 3,9po)
-
Can power up to 4 large lights or 6 small ights
-
Wall attachment (3 screws/pegs provided)
-
Maximum over-current protection 15A
-
Use copper conductors exclusively
-
Indoor & outdoor use
-
Protection index IP-55
-
3 screws & 3 pegs provided for wall attachment
-
Integrated supplementary protection circuit breaker, in front of the power supply 5A
