Description
- Product Name: 4.5″ Bore x 16″ Stroke Hydraulic Cylinder
- Specifications:
- Outer Diameter: 4.5 in
- Rod Diameter: 2 in
- Overall Length: 27.25 in
- PSI Rating: 3500 PSI
- Column Load: 37,700 LBs
- Oil Volume: 3.48 QTs
- Rod Type: Chrome Plated
- Rod End: Pin Hole
- Action: Double Acting
- Stroke: 16 in
- Extended Length: 41 in
- Retracted Length: 25 in
- Ports: SAE 8
- Style: Welded
- Durability: Built to withstand heavy-duty applications with high load capabilities.
- Compatibility: Ideal for a variety of uses, providing reliable performance across different industries.
- Manufacturer: Produced by Northern Hydraulics, known for exceptional hydraulic products.
NOTE! Ensure your measurements and applications are correct to prevent damage. Warranty does not cover misuse.
Same-Day Shipping: Orders placed before 3 pm will ship the same day (excluding weekends and holidays).
Free Ground Continental US Shipping!
Tariff-FREE cylinders.
Made in Europe.
If you need assistance selecting the right hydraulic cylinder replacement, contact us at:
(800) 823-4937
