Description
- Specifications:
- Outer Diameter: 4.5 in
- Rod Diameter: 2 in
- Stroke: 36 in
- Overall Length: 47.25 in
- Extended Length: 81 in
- Retracted Length: 45 in
- PSI Rating: 3500 PSI
- Column Load: 27,400 lbs
- Oil Volume: 7.83 QTs
- Rod Type: Chrome Plated
- Rod End: Pin Hole
- Action: Double Acting
- Style: Welded
- Ports: SAE 8
- Durability: Designed with heavy-duty materials to withstand high pressure and ensure longevity in demanding applications.
- Versatile Use: Perfect for a variety of hydraulic applications, making it a reliable choice for professionals and hobbyists alike.
- Easy Installation: The welded style and pin hole rod end facilitate straightforward installation in existing setups.
- Performance: Engineered for reliable operation, ensuring consistent performance under load with a maximum weight bearing capacity of 27,400 lbs.
NOTE: Chrome-plated rod is NOT induction hardened (temperature treated). Possible bent rod results from misuse (wrong measurements or type of application); such cases are not covered under warranty.
Same-Day Shipping: All orders made until 3 PM will be shipped the same day (except weekends and holidays).
Free Ground Continental US Shipping!
Tariff-FREE cylinders.
Made in Europe.
If you need assistance choosing a proper hydraulic cylinder replacement, do not hesitate to contact us:(800) 823-4937
