Description
- Dimensions: Outer Diameter: 4.5 in, Rod Diameter: 2 in, Overall Length: 23.25 in.
- Stroke: 12 in, Extended Length: 33 in, Retracted Length: 21 in.
- Pressure Rating: 3500 PSI, suitable for heavy-duty applications.
- Load Capacity: Column Load of 37,700 LBs, ensuring superior lifting power.
- Oil Volume: 2.61 QTs, optimizing operational efficiency.
- Rod Type: Chrome Plated, designed for durability and strength.
- Rod End: Pin Hole, compatible with various mounting options.
- Action: Double Acting, providing smooth operation in both directions.
- Style: Welded, specifically engineered for robustness.
- Ports: SAE 8, easy integration into existing hydraulic systems.
Note: The chrome-plated rod is not induction hardened and may be susceptible to bending if not installed properly. Warranty does not cover misuse.
Enjoy Same-Day Shipping: All orders made until 3 PM will be shipped out the same day (excluding weekends and holidays).
Free Ground Shipping: Available for all orders within the Continental US.
Tariff-FREE cylinders!
Manufactured in Europe.
If you have any questions about choosing the right hydraulic cylinder for your needs, please reach out to us at (800) 823-4937.
