Description
- Specifications:
- Stroke Length: 24 inches
- Overall Length: 36.25 inches
- Extended Length: 58.25 inches
- Retracted Length: 34.25 inches
- Outer Diameter: 2.38 inches
- Rod Diameter: 1.125 inches
- Pressure Rating: 2500 PSI
- Column Load: 6,950 lbs
- Oil Volume: 1.3 quarts
- Rod Type: Chrome Plated
- Rod End: Clevis
- Action: Double Acting
- Ports: SAE 8
- Durability: Built to withstand demanding applications, this hydraulic cylinder features a welded construction for enhanced durability and performance.
- Versatility: Suitable for a wide range of applications, including agricultural, industrial, and construction operations.
- Easy Installation: Designed for straightforward installation with various mounting options available.
NOTE! Ensure proper measurements and application types to prevent misuse, which could result in bent rods not covered under warranty.
