Description
- Specifications:
- Bore Diameter: 2.38 in.
- Rod Diameter: 1.25 in.
- Stroke Length: 6 in.
- Overall Length: 16.69 in.
- Extended Length: 21 in.
- Retracted Length: 15 in.
- Pressure Rating: 3500 PSI
- Column Load: 9,400 LBs
- Oil Volume: 0.33 QTs
- Rod Type: Chrome Plated
- Rod End Type: Narrow Tube
- Action: Double Acting
- Style: Welded
- Ports Type: SAE 6
Experience exceptional performance and durability with our hydraulic cylinder. Designed for various applications in agricultural, industrial, and construction settings, this 2.38″ bore x 6″ stroke hydraulic cylinder is built to withstand tough conditions.
Key Features:
- Heavy-duty construction ensures long-lasting performance.
- Double acting action maximizes efficiency for various tasks.
- Chrome plated rod for enhanced corrosion resistance and longevity.
- 9,400 LBs column load capacity allows for heavy lifting.
- Compact design with a retracted length of just 15 in.
Usage Information:
This hydraulic cylinder is straightforward to install and compatible with numerous hydraulic systems. Maintain optimal performance by checking the cylinder for leaks and ensuring the proper hydraulic fluid level is maintained.
Order Information:
Get your hydraulic cylinder today with our 2-year warranty and free ground shipping within the Continental US. Enjoy tariff-free cylinders made in Europe.
If you need assistance choosing the right hydraulic cylinder for your applications, do not hesitate to contact us at (800) 823-4937.
