Description
- Specifications:
- Outer Diameter: 2.38 in
- Rod Diameter: 1.25 in
- Overall Length: 22.69 in
- PSI: 3500 PSI
- Column Load: 9,400 LBs
- Oil Volume: 0.65 QTs
- Rod Type: Chrome Plated
- Rod End: Narrow Tube
- Action: Double Acting
- Stroke: 12 in
- Extended Length: 33 in
- Retracted Length: 21 in
- Manufacturer: Northern Hydraulics
- Style: Welded
- Ports: SAE 6
- Key Benefits:
- Heavy-duty construction designed to withstand the toughest conditions.
- Double-acting design for enhanced efficiency in hydraulic applications.
- High-quality chrome plated rod for improved durability and resistance to wear.
- Compatible with various mounting options, making it versatile for different machinery.
- Free ground shipping within the Continental US.
- 2-year warranty for peace of mind.
NOTE! The chrome-plated rod is NOT induction hardened (Temperature treated). Misuse may result in a bent rod, which is not covered under warranty.
Same-Day Shipping: All orders made until 3 pm will be shipped the same day (except weekends and holidays).
Tariff-FREE cylinders. Made in Europe.
If you need assistance choosing a proper hydraulic cylinder replacement, do not hesitate to contact us: (800) 823-4937
